Product Details:
| Place of Origin: |
China |
| Brand Name: |
415 sprocket with spline hole |
| Certification: |
415 chain |
| Model Number: |
A5213T10-T18 |
Payment & Shipping Terms:
| Minimum Order Quantity: |
100pcs |
| Price: |
negotiation |
| Packaging Details: |
Packed in carton firstly,and then reinforced with wooden case for outer packing |
| Delivery Time: |
20 working days after received your payment |
| Payment Terms: |
T/T or western Union |
| Supply Ability: |
2,000pcs per month |
Detailed Product Description
| Product Name: |
415 Sprocket With Spline Hole |
Application: |
GEARING |
| Material: |
Steel |
Surface Treatment: |
Blackening |
| Standard: |
415 Chain |
Pitch: |
12.7 |
Go kart 415 sprocket with spline hole
Specifications:
|
Proudct Number |
Product Name |
Material |
Surface Treatment |
Teeth Number |
Weight(g) |
|
A5213T10 |
415 sprocket with spline hole |
steel
|
blacken |
10T |
|
|
A5213T11 |
blacken |
11T |
|
|
A5213T12 |
blacken |
12T |
|
|
A5213T13 |
blacken |
13T |
|
|
A5213T14 |
blacken |
14T |
74.8 |
|
A5213T15 |
blacken |
15T |
86.2 |
|
A5213T16 |
blacken |
16T |
98.2 |
|
A5213T17 |
blacken |
17T |
114.8 |
|
A5213T18 |
blacken |
18T |
125.5 |
Description:
415 sprocket with spline hole.
Sprockets are sized by the chain pitch and the number ofteeth. The more teeth, the larger the sprocket is. The larger the sprocket, the better your low-end power will be. Thesmaller the sprocket, the better your top-end speed will be.
However, small sprockets really punish the already weak low-end torque of the kart. For this reason some use torque converters. If you expect great performance from a smaller engine, they are a must.
For a single wheel drive, the sprocket can mount directly to the wheel so that there are no moving axle parts.
A chain and sprocket is a good and popular choice for the drive assembly, as they will wear better than a pulley system, are simple to install, and inexpensive.
We supply go kart sprocket for many famous OEM company and we have very compled service system:
|
|
